• Meets IEC 62196-2 2010 SHEET 2-llb (Mennekes, Type 2) EU European standard

• Attractive shape and easy to use, protection class IP54 (when mated)

Parameters

• Rated current: 32A

• Operation voltage: 230/415V AC

• Insulation resistance: > 1000MΩ (DC500V)

• Terminal temperature rise: < 50K

• Max voltage: 2000V

• Vibration resistance: Meets JDQ 53.3

• Contact impedance: 0.5mΩ max

Materials

• Shell Material: Thermo Plastic (Insulator inflammability UL94 VO)

• Contact Pins: Copper alloy, silver plating

• Sealing gasket: rubber or silicon rubber
